• Year
  • 1997 ?
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 249765

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • PLL, Phase-locked loop
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Details
  • Video-Taperecorder/-Player; Radio Control (+Remote Wire etc)
  • Power type and voltage
  • Alternating Current supply (AC) / 220-240 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Various materials
  • from Radiomuseum.org
  • Model: Video Cassette Recorder VR678 /02 - Philips Hungary, Rádió és
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 380 x 90 x 290 mm / 15 x 3.5 x 11.4 inch
  • Notes
  • Das Modell VR678 von Philips ist ein HiFi-Stereo VHS-Videorecorder (6-Kopf Gerät).

    Einige technische Daten u. Ausstattung:
    Empfangsteil, Kabeltuner VHF/UHF;
    Turbodrive Laufwerk für schnelles Spulen;
    Show View Programmierung;
    Shuttle Regler/Knopf für Vor- /Rücklauf und zur Ansteuerung von Video-Sequenzen;
    Frontseitiger AV-Anschluss (Chinch-Buchsen), hinter Abdeck-Klappe;
    Rückseite, 2 Scart-Buchsen (Euro-AV);
    Rückseite, Audio In/Out (Chinch-Buchsen);
    IR-Fernbedienung.

  • Net weight (2.2 lb = 1 kg)
  • 4 kg / 8 lb 13 oz (8.811 lb)
  • Author
  • Model page created by Jürgen Küting. See "Data change" for further contributors.
