• Country
• Malaysia

• Manufacturer / Brand
• Philips Malaysia; Petaling Jaya

• Year
• 1989/1990

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 254600

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common); ZF/IF 468/10700 kHz

• Wave bands
• Broadcast, Long Wave and FM or UHF.

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Line / Batteries (any type) / 120; 220; 240 / UM1: 6 × 1,5 Volt

• Loudspeaker
• 5 Loudspeakers

• Power out
• 8 W (max.)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Stereo Radio Cassette Recorder AW7502 /00 /05 - Philips Malaysia; Petaling

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 580 x 190 x 203 mm / 22.8 x 7.5 x 8 inch

• Notes

• 2 Ausführungen: .../00 for 220 Volt, .../05 for 240 Volt.
  Doppelcassettendeck, Equalizer, Bassbooster.

• Net weight (2.2 lb = 1 kg)
• 4.5 kg / 9 lb 14.6 oz (9.912 lb)
