• Country
• United States of America (USA)

• Manufacturer / Brand
• Philmore Mfg. Co. - Ajax Products Co.; New York, NY

• Year
• 1955 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 137001

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 12BE6 12BA6 12AV6 50C5 35W4

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• AC/DC-set / 115 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 3.5 inch = 8.9 cm

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: 5 Tube Superhet Receiver Kit 205 - Philmore Mfg. Co. - Ajax

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 6.75 x 4.25 x 3.5 inch / 171 x 108 x 89 mm

• Notes
• Philmore 205, 5 Tube AC-DC Radio, 5 Tube Superhet Receiver Kit;

• Literature/Schematics (1)
• - - Manufacturers Literature

• Author
• Model page created by a member from A. See "Data change" for further contributors.
