Quadrophonic Tape Deck QT-6600
Pioneer Corporation; Tokyo
- Country
- Japan
- Manufacturer / Brand
- Pioneer Corporation; Tokyo
- Year
- 1972 ?
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 81250
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Audio-Amplification
- Details
- Tape Recorder; Hi-Fi equipment
- Power type and voltage
- Alternating Current supply (AC) / 110; 120; 130; 220; 240 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Wooden case
- from Radiomuseum.org
- Model: Quadrophonic Tape Deck QT-6600 - Pioneer Corporation; Tokyo
- Shape
- Tablemodel, high profile (upright - NOT Cathedral nor decorative).
- Dimensions (WHD)
- 434 x 478 x 212 mm / 17.1 x 18.8 x 8.3 inch
- Notes
-
True quadophony, 4 microphone inputs, spool diameter up to 7 inches, auto-reverse; tape speed 3.75 and 7.5 ips.
Echte Quadrofonie, 4 Mikrofoneingänge, Spulen-Ø bis 18 cm, Auto-Reverse; 9,5 und 19 cm/sek.
- Net weight (2.2 lb = 1 kg)
- 17 kg / 37 lb 7.1 oz (37.445 lb)
- Mentioned in
- -- Original prospect or advert (1972 Pioneer Hi-Fi Stereo Components catalogue)
- Literature/Schematics (1)
- - - Manufacturers Literature (Pioneer QT-6600 brochure)
- Author
- Model page created by Peter Böhm. See "Data change" for further contributors.
