AM Stereo Receiver SM-Q300

AM Stereo Receiver SM-Q300; Pioneer Corporation; (ID = 2224626) Radio

AM Stereo Receiver SM-Q300; Pioneer Corporation; (ID = 326983) Radio
AM Stereo Receiver SM-Q300; Pioneer Corporation; (ID = 2532276) Radio AM Stereo Receiver SM-Q300; Pioneer Corporation; (ID = 2532279) Radio
AM Stereo Receiver SM-Q300; Pioneer Corporation; (ID = 2532277) Radio AM Stereo Receiver SM-Q300; Pioneer Corporation; (ID = 2532281) Radio
AM Stereo Receiver SM-Q300; Pioneer Corporation; (ID = 2532274) Radio AM Stereo Receiver SM-Q300; Pioneer Corporation; (ID = 2532275) Radio
AM Stereo Receiver SM-Q300; Pioneer Corporation; (ID = 2532278) Radio AM Stereo Receiver SM-Q300; Pioneer Corporation; (ID = 2532280) Radio
AM Stereo Receiver SM-Q300; Pioneer Corporation; (ID = 317082) Radio AM Stereo Receiver SM-Q300; Pioneer Corporation; (ID = 317084) Radio
Use red slider bar for more.
AM Stereo Receiver SM-Q300; Pioneer Corporation; (ID = 2532276) Radio
Pioneer Corporation;: AM Stereo Receiver SM-Q300 [Radio] ID = 2532276 1400x929
Select picture or schematic to display from thumbnails on the right and click for download.
For model AM Stereo Receiver SM-Q300, Pioneer Corporation; Tokyo

Country:  Japan
Manufacturer / Brand:  Pioneer Corporation; Tokyo
Year: 1961/1962 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 19: 6BE6 6BA6 12AX7 12AX7 6G-E12A 12AX7 12AX7 6AQ8 6AQ8 6BA6 6BA6 6BA6 6AN8 6AN8 6BQ5 6BQ5 6BQ5 6BQ5
Semiconductors (the count is only for transistors) SE-05b SE-05b OA79 OA79 OA70 OA70
Main principle Superheterodyne (common)
Wave bands Broadcast, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 100; 117 Volt
Loudspeaker - This model requires external speaker(s).
Power out 34 W (unknown quality)
from Radiomuseum.org Model: AM Stereo Receiver SM-Q300 - Pioneer Corporation; Tokyo
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 18.5 x 5.5 x 14 inch / 470 x 140 x 356 mm
Notes 2 independent AM tuners for early AM-stereo.
Net weight (2.2 lb = 1 kg) 26.61 lb (26 lb 9.8 oz) / 12.081 kg
Literature/Schematics (1) -- Schematic
Literature/Schematics (2) -- Original prospect or advert (Audio, Dec. 1961 + Feb. 1962)

Model page created by Gottfried Silberhorn. See "Data change" for further contributors.
