• Country
• France

• Manufacturer / Brand
• Pizon Bros (JMP); Paris

• Year
• 1961

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 70989

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 8

• Semiconductors

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz

• Wave bands
• Broadcast, Long Wave and more than two Short Wave bands.

• Power type and voltage
• Storage and/or dry batteries / 9 Volt

• Power out
• 1 W (unknown quality)

• Material
• Various materials

• from Radiomuseum.org
• Model: Translitor 850 - Pizon Bros JMP; Paris

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 300 x 200 x 120 mm / 11.8 x 7.9 x 4.7 inch

• Notes
• 8 transistor et 2 diodes - antenne ferrite, prise antenne voiture ou extérieure - pile CIPEL 9v type R1480 ou équivalente - réglage d'utilisation "économie" : 70-80ma - régime normal : 200ma - coffret bois gainé

• Net weight (2.2 lb = 1 kg)
• 3.2 kg / 7 lb 0.8 oz (7.048 lb)

• Price in first year of sale
• 534.00 Franc

• External source of data
• Serge Laffont/Martin Renoth

• Mentioned in
• - - Manufacturers Literature

• Author
• Model page created by Ernst Erb. See "Data change" for further contributors.
