- Country
- France
- Manufacturer / Brand
- Point Bleu; Paris - voir aussi Blaupunkt (D)
- Year
- 1934/1935
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 33893
ebay
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 491 kHz
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Details
- Visual Tuning Indicator pre Eye
- Power type and voltage
- Alternating Current supply (AC) / 110; 130; 150; 220; 250 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 20 cm = 7.9 inch
- Power out
- 3.5 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: W115 - Point Bleu; Paris - voir aussi
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 430 x 385 x 310 mm / 16.9 x 15.2 x 12.2 inch
- Notes
-
3 gammes d'ondes : OC de 19 à 55 m, PO de 200 à 575 m, GO de 800 à 2000 m. Antifading agissant sur lampes changeuse de fréquence et MF. Accord visuel par tube néon. Réglage de tonalité progressif. Lampe cadran : 1 x 4 V / 0.5 A.
Ébénisterie noyer verni.
Modèle pour 25 périodes sur demande.
- Price in first year of sale
- 3,300.00 FFR
- External source of data
- Serge Laffont/Martin Renoth
- Circuit diagram reference
- La Documentation du Revendeur - Radio
- Mentioned in
- Schémathèque Toute la Radio (STR) (No. 93)
- Literature/Schematics (1)
- -- Original prospect or advert (Le Petit Marseillais, 06.12.1934)
