Signal Generator 1108E-Y AN/URM-206

Polarad Electronics Corp.- Long Island, NY

  • Year
  • 1970 ??
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 206034

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 6
  • Number of Transistors
  • 2
  • Semiconductors
  • Main principle
  • Special type of reception - please describe.
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Alternating Current supply (AC) / 115; 230 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Signal Generator 1108E-Y AN/URM-206 - Polarad Electronics Corp.-
  • Shape
  • Rack
  • Dimensions (WHD)
  • 19 x 51 x 161 inch / 483 x 1295 x 4089 mm
  • Notes
  • Signalgenerator im 19 Zoll Gehäuse (ident mit US-Army AN/URM-206), Frequenzbereich 7 - 11 GHz (max 10mW). Klystron-Oszillator mit ZV1011A. Intern und extern modulierbar (CW,FM oder Puls). Eingebauter HF-Abschwächer.
  • Net weight (2.2 lb = 1 kg)
  • 42 lb 0 oz (42 lb) / 19.068 kg
  • Source of data
  • -- Original-techn. papers.
  • Author
  • Model page created by Rudolf Müller. See "Data change" for further contributors.
