NF-Pegelsender GF 73

Präcitronic Dresden, VEB; (Ostd.)

  • Year
  • 1973 ??
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 214426

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Wave bands
  • - without
  • Power type and voltage
  • Line / Batteries (any type) / 220 / 24 V / 4x1,5 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: NF-Pegelsender GF 73 - Präcitronic Dresden, VEB; Ostd
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 240 x 125 x 270 mm / 9.4 x 4.9 x 10.6 inch
  • Notes
  • NF-Pegelsender umschaltbare Festfrequenzreihen 30 Hz...15 kHz in 19 Schritten (Rundfunk) und 300...3400 Hz in 14 Schritten (Fernsprech);
    Ausgangsgsspannung regelbar 5 V...1 mV, Ausgang symmetrisch 2 oder 600 Ω.
    Stromversorgung intern mit 4 x 1,5-V-Zellen, extern mit 24-V-Batterie oder Netz.
