RC-Generator GF 22; Präcitronic Dresden, (ID = 210381) Equipment
Präcitronic Dresden,: RC-Generator GF 22 [Equipment] ID = 210381 800x556
Select picture or schematic to display from thumbnails on the right and click for download.
For model RC-Generator GF 22, Präcitronic Dresden, VEB; (Ostd.)

Country:  Germany
Manufacturer / Brand:  Präcitronic Dresden, VEB; (Ostd.)
Year: 1970–1972 ? Category: Service- or Lab Equipment
Semiconductors (the count is only for transistors) 13:
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker
Power out
from Radiomuseum.org Model: RC-Generator GF 22 - Präcitronic Dresden, VEB; Ostd
Material Metal case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 250 x 160 x 170 mm / 9.8 x 6.3 x 6.7 inch
Notes

Vier Messbereiche 2 Hz...20 kHz, Ausgangsspannung in 5 Bereichen 0...10 V stufenlos einstellbar. Ein Kaltleiter, ein Widerstandsnetzwerk (KME-Baustein Hescho).
Produktion wurde zum VEB Radio und Fernsehen Karl-Marx-Stadt (Chemnitz) verlagert und die Geräte dort mit gleichem Aussehen und gleichen Daten gebaut, auf der Frontseite auch das Logo PRÄCITRONIC. (Siehe auch Firmentext zu Praecitronic.)
Wurde 1970 von Clamann & Grahnert entwickelt.

Net weight (2.2 lb = 1 kg) 5 kg / 11 lb 0.2 oz (11.013 lb)
Price in first year of sale 1'415.00 Mark
Source of data Radiokatalog Band 2, Ernst Erb
Mentioned in -- Original prospect or advert
Literature/Schematics (1) Anders, Schaltungssammlung der Messgeräte, S. 106ff

Model page created by Bernd Pötzsch. See "Data change" for further contributors.
