• Country
• Spain

• Manufacturer / Brand
• Promax; Barcelona

• Year
• 1980 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 173768

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 125; 220 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Frecuencímetro FD-915 - Promax; Barcelona

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Notes
• Display 8 dígitos LED.
  Input: 20 MHz ó 200 MHz seleccionable.

• Author
• Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
