Generador de Funciones GF-230
Promax; Barcelona
- Country
- Spain
- Manufacturer / Brand
- Promax; Barcelona
- Year
- 1990 ??
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 173773
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 220; 230; 240 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Generador de Funciones GF-230 - Promax; Barcelona
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 212 x 102 x 241 mm / 8.3 x 4 x 9.5 inch
- Notes
- 0,1 -1 MHz. Salida: senoidal, triangulas, cuadrada, TTL
- Net weight (2.2 lb = 1 kg)
- 1.7 kg / 3 lb 11.9 oz (3.744 lb)
- Literature/Schematics (1)
- - - Manufacturers Literature
- Author
- Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
