Generador de Funciones GF-1000

• Country
• Spain

• Manufacturer / Brand
• Promax; Barcelona

• Year
• 1980 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 173775

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 220; 230; 240 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Generador de Funciones GF-1000 - Promax; Barcelona

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 165 x 103 x 270 mm / 6.5 x 4.1 x 10.6 inch

• Notes

• Frecuencias: 0,1 -1 MHz.
  Salida: senoidal, triangular y cuadrada, amplitud variable +/- 5 V @ 600 Ω
  Salida independiente TTL

• Net weight (2.2 lb = 1 kg)
• 1.7 kg / 3 lb 11.9 oz (3.744 lb)

• Source of data
• - - Manufacturers Literature

• Author
• Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
