Mira Electrónica GV-298

• Country
• Spain

• Manufacturer / Brand
• Promax; Barcelona

• Year
• 1985 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 173781

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 220; 230; 240 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Mira Electrónica GV-298 - Promax; Barcelona

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 102 x 90 x 241 mm / 4 x 3.5 x 9.5 inch

• Notes

• Sistema PAL; 37 - 865 MHz.
  Versiones:
  GV-298 PAL B,G,H. Canales CCIR.
  GV-298-2 Pal DK. Canales OIRT.
  GV-298-4 PAL I. Canales CCIR.
  GV-298-6 PAL N. Canales FCC.

  Diese Gerät ist baugleich mit dem König F610.

• Net weight (2.2 lb = 1 kg)
• 2.250 kg / 4 lb 15.3 oz (4.956 lb)

• Literature/Schematics (1)
• - - Manufacturers Literature

• Author
• Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
