Mira Electrónica GV-698

Promax; Barcelona

Data
Forum
Pictures
Collections

  • Year
  • 1990 ??
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 173782

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 125; 220; 230; 240 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Mira Electrónica GV-698 - Promax; Barcelona
  • Shape
  • Tablemodel without push buttons, Mantel/Midget/Compact up to 14
  • Dimensions (WHD)
  • 288 x 102 x 247 mm / 11.3 x 4 x 9.7 inch
  • Notes
  • Sistema NTSC/PAL/SECAM según versiones; 37 - 865 MHz.
    Versiones:
    GV-698 NTSC/PAL. Canales CCIR.
    GV-698/1 NTSC/PAL. Canales FCC.
    GV-698/2 NTSC/PAL. Canales OIRT.
    GV-698/3 SECAM/NTSC/PAL. Canales CCIR.
    GV-698/5 SECAM/NTSC/PAL. Canales OIRT.
    GV-698/6 NTSC/PAL N. Canales FCC.
    GV-698/8 NTSC/PAL M. Canales FCC.
    GV-698/11 Completa SECAM/NTSC/PAL. Canales CCIR. Incluye opciones -2 ZWEITON, -3 TELETEXT & VPS, -4 NICAM.
  • Net weight (2.2 lb = 1 kg)
  • 3 kg / 6 lb 9.7 oz (6.608 lb)
  • Literature/Schematics (1)
  • - - Manufacturers Literature
  • Author
  • Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
