Multímetro Digital MD-100
Promax; Barcelona
- Country
- Spain
- Manufacturer / Brand
- Promax; Barcelona
- Year
- 1980 ??
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 173791
Foto cortesía vendedor eBay Hifi-attack
Catálogo posiblemente de 1980
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 220; 230; 240 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Multímetro Digital MD-100 - Promax; Barcelona
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 165 x 103 x 260 mm / 6.5 x 4.1 x 10.2 inch
- Notes
- Multímetro de V, I, R en =/~.
- Net weight (2.2 lb = 1 kg)
- 2.3 kg / 5 lb 1.1 oz (5.066 lb)
- Source of data
- - - Manufacturers Literature
- Author
- Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
