New Baby Q L75B

New Baby Q L75B; Pye Ltd., Radio (ID = 2297403) Radio New Baby Q L75B; Pye Ltd., Radio (ID = 194872) Radio
New Baby Q L75B; Pye Ltd., Radio (ID = 194873) Radio New Baby Q L75B; Pye Ltd., Radio (ID = 965463) Radio
New Baby Q L75B; Pye Ltd., Radio (ID = 965465) Radio New Baby Q L75B; Pye Ltd., Radio (ID = 1505915) Radio
New Baby Q L75B; Pye Ltd., Radio (ID = 1505916) Radio New Baby Q L75B; Pye Ltd., Radio (ID = 1505917) Radio
New Baby Q L75B; Pye Ltd., Radio (ID = 1505918) Radio New Baby Q L75B; Pye Ltd., Radio (ID = 1505919) Radio
Use red slider bar for more.
New Baby Q L75B; Pye Ltd., Radio (ID = 2297403) Radio
Pye Ltd., Radio: New Baby Q L75B [Radio] ID = 2297403 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model New Baby Q L75B, Pye Ltd., Radio Works; Cambridge

Country:  Great Britain (UK)
Manufacturer / Brand:  Pye Ltd., Radio Works; Cambridge
Year: 1946 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: DK32 DF33 DAC32 DL35
Main principle Superheterodyne (common); ZF/IF 465 kHz
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Dry Batteries / 90 + 1,5 Volt
Loudspeaker Permanent or electro-dynamic (moving coil), system not known yet. / Ø 6 inch = 15.2 cm
Power out
from Radiomuseum.org Model: New Baby Q L75B - Pye Ltd., Radio Works;
Material Leather / canvas / plastic - over other material
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 13 x 12 x 7 inch / 330 x 305 x 178 mm
Notes Released June 1946 price £13 10s 0d plus £2 18s 1d purchase tax. Blue rexine covered wooden case.
Price in first year of sale 16.00 GBP
Source of data Radio! Radio!
Literature/Schematics (1) -- Collector info (Sammler)

Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.
