• Country
• Great Britain (UK)

• Manufacturer / Brand
• Pye Ltd., Radio Works; Cambridge

• Year
• 1961 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 92004

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 7

• Semiconductors
• AF115 NKT153 NKT154 NKT255 NKT252 NKT251 NKT251

• Main principle
• Superheterodyne (common); ZF/IF 470 kHz

• Wave bands
• Broadcast plus more than 2 Short Wave bands.

• Power type and voltage
• Dry Batteries / 6 × 1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 7 inch = 17.8 cm

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: PE12TBQ - Pye Ltd., Radio Works;

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 13 x 9.5 x 4.5 inch / 330 x 241 x 114 mm

• Notes
• 3× SW. Export model.

• Net weight (2.2 lb = 1 kg)
• 5 kg / 11 lb 0.2 oz (11.013 lb)

• Source of data
• -- Collector info (Sammler)

• Literature/Schematics (1)
• - - Manufacturers Literature

• Author
• Model page created by Howard Craven. See "Data change" for further contributors.
