Poppet 1072

Poppet 1072; Pye Ltd., Radio (ID = 2160375) Radio
Poppet 1072; Pye Ltd., Radio (ID = 2141147) Radio Poppet 1072; Pye Ltd., Radio (ID = 2141148) Radio
Poppet 1072; Pye Ltd., Radio (ID = 2141149) Radio Poppet 1072; Pye Ltd., Radio (ID = 2141150) Radio
Poppet 1072; Pye Ltd., Radio (ID = 2141151) Radio Poppet 1072; Pye Ltd., Radio (ID = 2141152) Radio
Poppet 1072; Pye Ltd., Radio (ID = 213144) Radio Poppet 1072; Pye Ltd., Radio (ID = 2160376) Radio
Use red slider bar for more.
Poppet 1072; Pye Ltd., Radio (ID = 2141147) Radio
Pye Ltd., Radio: Poppet 1072 [Radio] ID = 2141147 900x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Poppet 1072, Pye Ltd., Radio Works; Cambridge

Country:  Great Britain (UK)
Manufacturer / Brand:  Pye Ltd., Radio Works; Cambridge
Year: 1970 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6:
Main principle Superheterodyne (common)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Dry Batteries / 2 × 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 2 inch = 5.1 cm
Power out
from Radiomuseum.org Model: Poppet 1072 - Pye Ltd., Radio Works;
Material Plastics (no bakelite or catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 5 x 3 x 1.5 inch / 127 x 76 x 38 mm
Notes

Made for PYE in Singapore. Tiny circuit diagram inside. Earphone socket on back cover.

Very similar to the Belgian Siera SX1072 model.

Net weight (2.2 lb = 1 kg) 0.3 kg / 0 lb 10.6 oz (0.661 lb)
Mentioned in -- Collector info (Sammler)

Model page created by Howard Craven. See "Data change" for further contributors.
