• Country
• Great Britain (UK)

• Manufacturer / Brand
• Pye Ltd., Radio Works; Cambridge

• Year
• 1940

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 202045

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• CCH35 EF9 or EF39 CBL31 CY31

• Main principle
• Superheterodyne (common); ZF/IF 467 kHz

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• AC/DC-set / 200-250 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: QU [AC/DC] - Pye Ltd., Radio Works;

• Shape
• Tablemodel, with any shape - general.

• Notes

• Transportable AC/DC mains receiver in a two-tone walnut cabinet with a carrying handle on top.

  1940 to 1942 on many UK models Edge connect (P8) are replaced with otherwise identical Octal (IO). sometimes even US imports rather than BVA production. In 1945 Mullard issued instructions on how to replace P8 valves with Octal and cross reference table.

• Literature/Schematics (1)
• Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (496)

• Author
• Model page created by Howard Craven. See "Data change" for further contributors.
