StereoMaster Hi-Fidelity Stereo Projection System 4006

Pye (N.Z.) Ltd.; Waihi

  • Anno
  • 1968
  • Categoria
  • Registratore audio/video e/o riproduttore
  • Radiomuseum.org ID
  • 360548

 Specifiche tecniche

  • Numero di transistor
  • A semiconduttori.
  • Semiconduttori
  • Principio generale
  • Amplificatore audio
  • Gamme d'onda
  • - senza
  • Particolarità
  • Giradischi o cambiadischi
  • Tensioni di funzionamento
  • Alimentazione a corrente alternata (CA) / 50Hz, 230 Volt
  • Potenza d'uscita
  • 8 W (max.)
  • Radiomuseum.org
  • Modello: StereoMaster Hi-Fidelity Stereo Projection System 4006 - Pye N.Z. Ltd.; Waihi
  • Dimensioni (LxAxP)
  • 27.69 x 0 x 15.32 inch / 703 x 0 x 389 mm
  • Annotazioni
  • PYE StereoMaster 4006 Hi-Fidelity Stereo Projection System

    HI-FIDELITY STEREO. A luxurious complement to any lounge. This most elegant style bookshelf model is extremely functional.

    SPECIFICATIONS:

    • POWER OUTPUT (per channel): 4 watts R.M.S. at 1000 Hz
    • MODE: Stereo, Class A
    • RESPONSE: Manually adjustable with BASS and TREBLE CONTROLS.
    • CHANNEL BALANCE: Manual
    • DUAL CONTROLS: For simultaneous adjustment of both channels.
    • ON/OFF Switch: Manual on record player.
    • SPEAKERS (dual): 1-Crossover R. & A type 9106 P12 10½in x 6½in 3 ohm, selected cone resonance of 50 Hz. 2-DAVRED type TW 260 3in round ("Tweeter").
    • RECORD PLAYER: Garrard type SP25 Player or Garrard 3000 changer. Sorotone ceramic cartridge.

    See also PYE StereoMaster 4006c with legs and platter rack.

  • Bibliografia
  • -- Original prospect or advert (Press 28 May 1968 Page 5)
  • Letteratura / Schemi (1)
  • -- Original prospect or advert (Press 21 September 1969 Page 3)
  • Autore
  • Modello inviato da Brian Stevens. Utilizzare "Proponi modifica" per inviare ulteriori dati.
