- Country
- France
- Manufacturer / Brand
- Pygmy, Ciate-Pygmy (SCIP, CIATE); Paris, La Plaine St. Denis, La Courneuve
- Year
- 1973
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 271763
- Number of Transistors
- 1
- Main principle
- Superheterodyne (common); ZF/IF 480 kHz
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Dry Batteries / 2 x 4.5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 9 cm = 3.5 inch
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Lem - Pygmy, Ciate-Pygmy SCIP, CIATE
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 210 x 135 x 6.8 mm / 8.3 x 5.3 x 0.3 inch
- Notes
-
2 gammes d'ondes: PO de 186 à 578 m et GO de 1115 à 1829 m, et 3 stations préréglées: FR1, EUR1 et LUX. 1 transistor + 1 circuit intégré.
Coffret matière plastique de différents couleurs (gris, orange, ivoire, ...)
Poids avec piles.
- Net weight (2.2 lb = 1 kg)
- 1 kg / 2 lb 3.2 oz (2.203 lb)
- Mentioned in
- Pygmy, Une grande marque pour des petits postes. (Fiche No. 67, p.185)
