• Country
• United States of America (USA)

• Manufacturer / Brand
• Radio Mfg. Engineers, Inc. (RME); Peoria, IL

• Year
• 1950 ?

• Category
• Pre-stage (adaptor for SW/FM/VHF/UHF incl. built-in), Frequency converter

• Radiomuseum.org ID
• 52571

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• 6AK5 6AK5 6J6 5Y3G VR150

• Main principle
• RF Converter/Adapter (not voltage converter)

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 115 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: VHF-152 - Radio Mfg. Engineers, Inc. RME

• Shape
• Tablemodel, with any shape - general.

• Notes
• The VHF-125 Frequency Converter has been designed for use with a conventional communication type receiver to extend its range to cover the 10, 6 and 2 meter amateur bands.
  Output Frequency: 7 mc (7000 kc)
  Frequency Range: 27.5 - 29.8 mc
                             49.5 - 54.2 mc
                           143.8 -148.2 mc

• Circuit diagram reference
• Rider's Perpetual, Volume 19 = 1949 and before

• Author
• Model page created by Peter Rutishauser. See "Data change" for further contributors.
