Synchrovox 648A Luxe (648 Luxe)

Synchrovox 648A Luxe ; Radio L.L. Lucien (ID = 1320248) Radio Synchrovox 648A Luxe ; Radio L.L. Lucien (ID = 1320249) Radio
Synchrovox 648A Luxe ; Radio L.L. Lucien (ID = 1320250) Radio Synchrovox 648A Luxe ; Radio L.L. Lucien (ID = 2138101) Radio
Synchrovox 648A Luxe ; Radio L.L. Lucien (ID = 1448465) Radio Synchrovox 648A Luxe ; Radio L.L. Lucien (ID = 1448463) Radio
Synchrovox 648A Luxe ; Radio L.L. Lucien (ID = 1448464) Radio
Use red slider bar for more.
Synchrovox 648A Luxe ; Radio L.L. Lucien (ID = 1320248) Radio
Radio L.L. Lucien: Synchrovox 648A Luxe [Radio] ID = 1320248 900x712
Select picture or schematic to display from thumbnails on the right and click for download.
For model Synchrovox 648A Luxe (648 Luxe), Radio L.L. (Lucien Levy, LL Radio), S.A.E.D.R.A., Douglas; Paris

Country:  France
Manufacturer / Brand:  Radio L.L. (Lucien Levy, LL Radio), S.A.E.D.R.A., Douglas; Paris
alternative name

LL || Radio LL
Year: 1947/1948 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECH3 EF9 EBF2 EL3N EM4 1883
Main principle Superheterodyne (common)
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Details
Power type and voltage Alternating Current supply (AC)
Loudspeaker Permanent or electro-dynamic (moving coil), system not known yet. / Ø 21 cm = 8.3 inch
Power out
from Radiomuseum.org Model: Synchrovox 648A Luxe - Radio L.L. Lucien Levy, LL
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 490 x 380 x 270 mm / 19.3 x 15 x 10.6 inch
Notes

4 gammes d'ondes de 16 à 2000 m, dont 2 OC étalées de 15 à 51 m. Changeur de tonalité. Prise pick-up.

Modèle spécial pour 25-50 périodes.

Même modèle que le Synchrovox 647A Luxe, mais avec 2 OC. Voir aussi modèle Super-Tropical 650 au même présentation.

Dans certaines publicités ce modèle est appellé 648 Luxe.

Mentioned in -- Original prospect or advert

Model page created by Mark Hippenstiel. See "Data change" for further contributors.



All listed radios etc. from Radio L.L. (Lucien Levy, LL Radio), S.A.E.D.R.A., Douglas; Paris
Here you find 369 models, 259 with images and 72 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
