Realistic 10-Transistor Jetstream 12-626

Realistic 10-Transistor Jetstream 12-626; Radio Shack Tandy, (ID = 2373742) Radio
Use red slider bar for more.
Realistic 10-Transistor Jetstream 12-626; Radio Shack Tandy, (ID = 2373742) Radio
Radio Shack Tandy,: Realistic 10-Transistor Jetstream 12-626 [Radio] ID = 2373742 439x332
Select picture or schematic to display from thumbnails on the right and click for download.
For model Realistic 10-Transistor Jetstream 12-626, Radio Shack (Tandy, Realistic, Micronta); USA:
Radio Shack catalog, 1967, page 107

Country:  United States of America (USA)
Manufacturer / Brand:  Radio Shack (Tandy, Realistic, Micronta); USA
Year: 1967–1969 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 10:
Main principle Super-Heterodyne (Super in general)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Dry Batteries / AA: 4 x 1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Realistic 10-Transistor Jetstream 12-626 - Radio Shack Tandy, Realistic,
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 6 x 3.5 x 1.5 inch / 152 x 89 x 38 mm
Notes

Realistic 10-Transistor Jetstream Model 12-626.
Receives AM and VHF Aircraft band.
Telescopic antenna. Earphones jack.

Price in first year of sale 21.95 USD
Mentioned in Radio Shack Catalog (1967, page 107)

Model page created by Franz Scharner. See "Data change" for further contributors.
