Realistic DX-75

Realistic DX-75; Radio Shack Tandy, (ID = 1811348) Radio

Realistic DX-75; Radio Shack Tandy, (ID = 1811349) Radio

Realistic DX-75; Radio Shack Tandy, (ID = 1811350) Radio
Realistic DX-75; Radio Shack Tandy, (ID = 1811346) Radio Realistic DX-75; Radio Shack Tandy, (ID = 1811347) Radio
Use red slider bar for more.
Realistic DX-75; Radio Shack Tandy, (ID = 1811346) Radio
Radio Shack Tandy,: Realistic DX-75 [Radio] ID = 1811346 1400x908
Select picture or schematic to display from thumbnails on the right and click for download.
For model Realistic DX-75, Radio Shack (Tandy, Realistic, Micronta); USA:
1967 Radio Shack Catalog.

Country:  United States of America (USA)
Manufacturer / Brand:  Radio Shack (Tandy, Realistic, Micronta); USA
Year: 1967 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: 6CL8A 12BA6 12AV6 6AQ5A
Main principle Super-Heterodyne (Super in general)
Wave bands Broadcast plus more than 2 Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 60 cycles, 105-125 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Realistic DX-75 - Radio Shack Tandy, Realistic,
Material Metal case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 19.531 x 6.313 x 14.25 inch / 496 x 160 x 362 mm
Notes

Radio Shack Realistic DX-75.  General coverage AM receiver covering 550 kHz to 30 MHz.  Cabinet is vinyl covered steel.  Announced as "new" in the 1967 Radio Shack catalog.

Net weight (2.2 lb = 1 kg) 15 lb 0 oz (15 lb) / 6.810 kg
Price in first year of sale 69.95 USD
Mentioned in Radio Shack Catalog (1967 page 108)
Literature/Schematics (3) Shortwave Receivers - Past & Present (3rd ed.) (3rd edition page 345)

Model page created by Martin Bösch. See "Data change" for further contributors.
