Realistic Patrolman PRO-9 20-164

Radio Shack (Tandy, Realistic, Micronta); USA

  • Year
  • 1978 ??
  • Category
  • Amateur-Receiver (amateur bands, may include broadcast bands)
  • Radiomuseum.org ID
  • 140129

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Line / Batteries (any type) / 120 / 12 Volt
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Realistic Patrolman PRO-9 20-164 - Radio Shack Tandy, Realistic,
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 9.5 x 3 x 9.5 inch / 241 x 76 x 241 mm
  • Notes
  • Realistic Patrolman PRO-9, VHF Scanning & Tunable Monitor Receiver;
    148 - 175 MHz, squelch control, 8 X-tal controlled preset channels, manual tuning, phones jack.

    Made in Japan

  • Source of data
  • -- Collector info (Sammler)
  • Author
  • Model page created by a member from A. See "Data change" for further contributors.
