For model STA-52B Realistic 31-2080, Radio Shack (Tandy, Realistic, Micronta); USA:
scanned from service manual cover

Country:  United States of America (USA)
Manufacturer / Brand:  Radio Shack (Tandy, Realistic, Micronta); USA
Year: 1979 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 32:
Main principle Superhet with RF-stage; ZF/IF 455/10700 kHz; 3 AF stage(s)
Tuned circuits 6 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 120 Volt
Loudspeaker - This model requires external speaker(s).
Power out 32 W (unknown quality)
from Radiomuseum.org Model: STA-52B Realistic 31-2080 - Radio Shack Tandy, Realistic,
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 17.2 x 5.2 x 11.25 inch / 437 x 132 x 286 mm
Notes 16 Watts/channel minimum.
Price in first year of sale 200.00 $
Literature/Schematics (1) - - Manufacturers Literature

Model page created by Joe Sousa. See "Data change" for further contributors.
