• Country
• Portugal

• Manufacturer / Brand
• Radio Escola, Lisboa

• Year
• 1960 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 78640

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 6AT6 6BA6 6AQ5 6X4 EM34

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 cm = 4.7 inch

• Material
• Metal case

• from Radiomuseum.org
• Model: Sinfonia P2 - Radio Escola, Lisboa

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 220 x 145 x 120 mm / 8.7 x 5.7 x 4.7 inch

• Notes

• Signal Tracer

  The original kit, according to the  presented schematic, was built with an aternative tube range: 6AT6; 6SK7; 6V6; 5Y3, EM34

• Net weight (2.2 lb = 1 kg)
• 2.7 kg / 5 lb 15.2 oz (5.947 lb)

• Author
• Model page created by Mario Coelho. See "Data change" for further contributors.
