• Year
  • 1962 ?
  • Category
  • Car Radio, perhaps also + sound player/recorder
  • Radiomuseum.org ID
  • 130788
    • alternative name: SFRT

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 4
  • Number of Transistors
  • 2
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast, Long Wave and Short Wave.
  • Power type and voltage
  • Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: H12 A3P - Radiomatic, S.F.R.T. SFRT;
  • Shape
  • Chassis only or for «building in»
  • Notes
  • 3 gammes d'ondes dont 1 bande étalée (BE) sur 49 m. Étage HF accordée, étage de sortie transistorisée en push-pull.

    Alimentation sur 12 V, négatif à la masse.

  • Mentioned in
  • -- Schematic
  • Literature/Schematics (1)
  • -- Original prospect or advert
  • Author
  • Model page created by Jacky Parmentier. See "Data change" for further contributors.
