Jubileumsuper med FM

Jubileumsuper med FM ; Radionette; Oslo (ID = 107109) Radio Jubileumsuper med FM ; Radionette; Oslo (ID = 2456943) Radio
Jubileumsuper med FM ; Radionette; Oslo (ID = 2456940) Radio Jubileumsuper med FM ; Radionette; Oslo (ID = 2456942) Radio
Jubileumsuper med FM ; Radionette; Oslo (ID = 2456937) Radio Jubileumsuper med FM ; Radionette; Oslo (ID = 2456938) Radio
Jubileumsuper med FM ; Radionette; Oslo (ID = 2456939) Radio Jubileumsuper med FM ; Radionette; Oslo (ID = 2456941) Radio
Jubileumsuper med FM ; Radionette; Oslo (ID = 2456944) Radio
Use red slider bar for more.
Jubileumsuper med FM ; Radionette; Oslo (ID = 107109) Radio
Radionette; Oslo: Jubileumsuper med FM [Radio] ID = 107109 673x354
Select picture or schematic to display from thumbnails on the right and click for download.
For model Jubileumsuper med FM, Radionette; Oslo

Country:  Norway
Manufacturer / Brand:  Radionette; Oslo
Year: 1954–1956 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: ECC85 ECH81 EAF42 EF22 EM34 EL41 5Y3GT
Main principle Superheterodyne (common); ZF/IF 455 kHz
Wave bands Broadcast, (BC) Long Wave (LW), 2 x SW and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110-230 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 23 cm = 9.1 inch
Power out
from Radiomuseum.org Model: Jubileumsuper med FM - Radionette; Oslo
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 660 x 330 x 200 mm / 26 x 13 x 7.9 inch
Notes ECC arrived in 1954 - therefore this is the earliest date for this model.
Price in first year of sale 575.00 NKr
Mentioned in - - Data from my own collection

Model page created by Ernst Rykkje. See "Data change" for further contributors.
