Menuett 2 FM

Menuett 2 FM ; Radionette; Oslo (ID = 1839155) Radio

Menuett 2 FM ; Radionette; Oslo (ID = 1839038) Radio

Menuett 2 FM ; Radionette; Oslo (ID = 1839040) Radio
Menuett 2 FM ; Radionette; Oslo (ID = 488626) Radio Menuett 2 FM ; Radionette; Oslo (ID = 488628) Radio
Menuett 2 FM ; Radionette; Oslo (ID = 488625) Radio Menuett 2 FM ; Radionette; Oslo (ID = 488627) Radio
Menuett 2 FM ; Radionette; Oslo (ID = 488629) Radio Menuett 2 FM ; Radionette; Oslo (ID = 1838938) Radio
Use red slider bar for more.
Menuett 2 FM ; Radionette; Oslo (ID = 488626) Radio
Radionette; Oslo: Menuett 2 FM [Radio] ID = 488626 933x410
Select picture or schematic to display from thumbnails on the right and click for download.
For model Menuett 2 FM, Radionette; Oslo:
Frontansicht

Country:  Norway
Manufacturer / Brand:  Radionette; Oslo
Year: 1969 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 3: ECH81 EBF89 ECL86
Semiconductors (the count is only for transistors) 2: AF124 AF125
Main principle Superheterodyne (common); ZF/IF 455 kHz
Wave bands Broadcast, (BC) Long Wave (LW), 2 x SW and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Menuett 2 FM - Radionette; Oslo
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 570 x 225 x 190 mm / 22.4 x 8.9 x 7.5 inch
Price in first year of sale 598.00 NKr
Source of data -- Collector info (Sammler)

Model page created by Ernst Rykkje. See "Data change" for further contributors.



All listed radios etc. from Radionette; Oslo
Here you find 134 models, 124 with images and 45 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
