Romanta S581A

Romanta S581A; Radio Popular, (ID = 1046031) Radio Romanta S581A; Radio Popular, (ID = 1046032) Radio
Romanta S581A; Radio Popular, (ID = 1046033) Radio Romanta S581A; Radio Popular, (ID = 1046034) Radio
Romanta S581A; Radio Popular, (ID = 1046036) Radio Romanta S581A; Radio Popular, (ID = 1046040) Radio
Romanta S581A; Radio Popular, (ID = 1046041) Radio Romanta S581A; Radio Popular, (ID = 1437006) Radio
Use red slider bar for more.
Romanta S581A; Radio Popular, (ID = 1046031) Radio
Radio Popular,: Romanta S581A [Radio] ID = 1046031 933x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Romanta S581A, Radio Popular, Bucharest

Country:  Romania
Manufacturer / Brand:  Radio Popular, Bucharest
Year: 1958 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 6H31 6F31 6BC32 6L31 EZ80
Main principle Super-Heterodyne (Super in general); ZF/IF 468 kHz; 1 AF stage(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 14 cm = 5.5 inch
Power out 2.5 W (unknown quality)
from Radiomuseum.org Model: Romanta S581A - Radio Popular, Bucharest
Material Wooden case
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 356 x 260 x 190 mm / 14 x 10.2 x 7.5 inch
Net weight (2.2 lb = 1 kg) 7.1 kg / 15 lb 10.2 oz (15.639 lb)

Model page created by Bekir Yurdakul. See "Data change" for further contributors.



All listed radios etc. from Radio Popular, Bucharest
Here you find 40 models, 30 with images and 17 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
