FM tuner kit 277-9207

FM tuner kit 277-9207; Radio Shack Tandy, (ID = 2422310) Kit

FM tuner kit 277-9207; Radio Shack Tandy, (ID = 2422311) Kit

FM tuner kit 277-9207; Radio Shack Tandy, (ID = 2422312) Kit

FM tuner kit 277-9207; Radio Shack Tandy, (ID = 2422313) Kit

FM tuner kit 277-9207; Radio Shack Tandy, (ID = 2422314) Kit

FM tuner kit 277-9207; Radio Shack Tandy, (ID = 2422315) Kit

FM tuner kit 277-9207; Radio Shack Tandy, (ID = 2422316) Kit

FM tuner kit 277-9207; Radio Shack Tandy, (ID = 2422317) Kit
FM tuner kit 277-9207; Radio Shack Tandy, (ID = 2422307) Kit FM tuner kit 277-9207; Radio Shack Tandy, (ID = 2422308) Kit
Use red slider bar for more.
FM tuner kit 277-9207; Radio Shack Tandy, (ID = 2422307) Kit
Radio Shack Tandy,: FM tuner kit 277-9207 [Kit] ID = 2422307 647x406
Select picture or schematic to display from thumbnails on the right and click for download.
For model FM tuner kit 277-9207, Radio Shack (Tandy, Realistic, Micronta); USA

Country:  United States of America (USA)
Manufacturer / Brand:  Radio Shack (Tandy, Realistic, Micronta); USA
Year: 1980 ? Category: Kit (Parts plus instruction) or building instructions only
Semiconductors (the count is only for transistors) 1: 2N3819 S042 µA703 TBA120T
Main principle ZF/IF 10700 kHz; 1 AF stage(s)
Tuned circuits 4 FM circuit(s)
Wave bands FM Broadcast Band Only
Details
Power type and voltage Direct Current supply (DC) / 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: FM tuner kit 277-9207 - Radio Shack Tandy, Realistic,
Material Printed Circuit Board
Shape Chassis only or for «building in»
Dimensions (WHD) 65 x 50 x 15 mm / 2.6 x 2 x 0.6 inch
Notes

Schematic has one transistor and three integrated circuits.

Price in first year of sale 1'195.00 BEF
Mentioned in B Tandy catalog, 1980, page 349

Model page created by Walter Van Brussel. See "Data change" for further contributors.
