• Country
• United States of America (USA)

• Manufacturer / Brand
• Radio Shack (Tandy, Realistic, Micronta); USA

• Year
• 1969

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 335802

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 117 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Wooden case

• from Radiomuseum.org
• Model: SA-100 Cat. No.= 30-1972 - Radio Shack Tandy, Realistic,

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 9 x 3 x 6.5 inch / 229 x 76 x 165 mm

• Price in first year of sale
• 29.95 USD

• Mentioned in
• Radio Shack Catalog (1979, page 22)

• Author
• Model page created by David Erali. See "Data change" for further contributors.
