Tandy Astronaut 50 Realistic 12-9236

Radio Shack (Tandy, Realistic, Micronta); USA

  • Year
  • 1980 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 280522

 Technical Specifications

  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast, (BC) Long Wave (LW), 2 x SW and FM or UHF.
  • Power type and voltage
  • Line / Batteries (any type) / 220-240 / C: 4 x 1.5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Tandy Astronaut 50 Realistic 12-9236 - Radio Shack Tandy, Realistic,
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 300 x 190 x 80 mm / 11.8 x 7.5 x 3.1 inch
  • Notes
  • DIN-Anschluss, Kopfhörer-Anschluss, Teleskop-Antenna, Anzeige-Instrument Batt/Feldstärke, C-Batterien

    Made in Taiwan

  • Net weight (2.2 lb = 1 kg)
  • 1.8 kg / 3 lb 15.4 oz (3.965 lb)
  • Author
  • Model page created by Bruce Cohen. See "Data change" for further contributors.
