• Year
  • 1968–1971
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 125991
    • alternative name: A. Ss. Popow, Riga || Kandava Radio Works || Riga Popov Radiotechnika Works

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast, Long Wave, more than 2 x SW plus FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 127; 220; 240 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Rigonda Marksman-Audio - Radiotehnika RT - after 1951
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 470 x 235 x 270 mm / 18.5 x 9.3 x 10.6 inch
  • Notes
  • UK export version of "RIGA-101" model, FM (Stereo) 88-104 MHz, 3 SW bands, built-in VHF/FM aerial, front controlled turnable ferrit antenna, DIN tape terminal, phono-in, set consists of two suitable speaker boxes type "AC 80-2-1" with 470×235×200 mm.
  • Source of data
  • -- Collector info (Sammler)
  • Author
  • Model page created by a member from A. See "Data change" for further contributors.
