Analizador Electronico - Signal Tracer BA4

Analizador Electronico - Signal Tracer BA4; Radio Watt Valgifson (ID = 1486338) Equipment

Analizador Electronico - Signal Tracer BA4; Radio Watt Valgifson (ID = 1486339) Equipment
Analizador Electronico - Signal Tracer BA4; Radio Watt Valgifson (ID = 1484387) Equipment Analizador Electronico - Signal Tracer BA4; Radio Watt Valgifson (ID = 1485596) Equipment
Analizador Electronico - Signal Tracer BA4; Radio Watt Valgifson (ID = 1485599) Equipment
Use red slider bar for more.
Analizador Electronico - Signal Tracer BA4; Radio Watt Valgifson (ID = 1484387) Equipment
Radio Watt Valgifson: Analizador Electronico - Signal Tracer BA4 [Equipment] ID = 1484387 900x675
Select picture or schematic to display from thumbnails on the right and click for download.
For model Analizador Electronico - Signal Tracer BA4, Radio Watt (Valgifson); Barcelona

Country:  Spain
Manufacturer / Brand:  Radio Watt (Valgifson); Barcelona
Year: 1957 ?? Category: Service- or Lab Equipment
Valves / Tubes 4: EF98 EL90 6E5 EZ80
Details
Power type and voltage Alternating Current supply (AC) / 125 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Analizador Electronico - Signal Tracer BA4 - Radio Watt Valgifson;
Material Metal case
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 270 x 200 x 155 mm / 10.6 x 7.9 x 6.1 inch
Notes

Faltan las sondas de AF y BF.

Net weight (2.2 lb = 1 kg) 5.1 kg / 11 lb 3.7 oz (11.233 lb)

Model page created by Jose Francisco Lama Barquero. See "Data change" for further contributors.
