11Q4 Ch= RC-335C
RCA (RCA Victor Co. Inc.); New York (NY)
- Country
- United States of America (USA)
- Manufacturer / Brand
- RCA (RCA Victor Co. Inc.); New York (NY)
- Year
- 1938
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 53093
-
- alternative name: RCA Manufacturing || Victor Talking Machine
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 11
- Main principle
- Superhet with RF-stage; ZF/IF 455 kHz
- Wave bands
- Broadcast, Long Wave and 2 x Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 105-250 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 8 inch = 20.3 cm
- Power out
- 10 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 11Q4 Ch= RC-335C - RCA RCA Victor Co. Inc.; New
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 18.5 x 21.5 x 11.2 inch / 470 x 546 x 284 mm
- Notes
- 3 pilot lamps (one Mazda 47 and two Mazda 44, 6.3v).
- External source of data
- Ernst Erb
- Source of data
- Guide to Old Radios
- Circuit diagram reference
- Rider's Perpetual, Volume 11 = ca. 1940 and before
- Mentioned in
- Machine Age to Jet Age III
- Literature/Schematics (1)
- RCA Victor Service Notes for 1938
- Literature/Schematics (2)
- Cathedral & Tombstone Radios (page 215.)
