14AX Ch=RC1001E

14AX Ch=RC1001E; RCA RCA Victor Co. (ID = 1050019) Radio

14AX Ch=RC1001E; RCA RCA Victor Co. (ID = 1050020) Radio

14AX Ch=RC1001E; RCA RCA Victor Co. (ID = 1050021) Radio

14AX Ch=RC1001E; RCA RCA Victor Co. (ID = 971197) Radio

14AX Ch=RC1001E; RCA RCA Victor Co. (ID = 971198) Radio

14AX Ch=RC1001E; RCA RCA Victor Co. (ID = 971199) Radio

14AX Ch=RC1001E; RCA RCA Victor Co. (ID = 971195) Radio
14AX Ch=RC1001E; RCA RCA Victor Co. (ID = 2169110) Radio
Use red slider bar for more.
14AX Ch=RC1001E; RCA RCA Victor Co. (ID = 2169110) Radio
RCA RCA Victor Co.: 14AX Ch=RC1001E [Radio] ID = 2169110 1280x955
Select picture or schematic to display from thumbnails on the right and click for download.
For model 14AX Ch=RC1001E, RCA (RCA Victor Co. Inc.); New York (NY)

Country:  United States of America (USA)
Manufacturer / Brand:  RCA (RCA Victor Co. Inc.); New York (NY)
alternative name

RCA Manufacturing || Victor Talking Machine
Year: 1940 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 12SA7 12SK7 12SQ7 50L6GT 35Z5GT
Main principle Superheterodyne (common); ZF/IF 455 kHz
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage AC/DC-set / 105-125 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
Power out 0.9 W (unknown quality)
from Radiomuseum.org Model: 14AX Ch=RC1001E - RCA RCA Victor Co. Inc.; New
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel without bush buttons, Mantel/Midget/Compact up to 14
Dimensions (WHD) 10.125 x 6.625 x 6.25 inch / 257 x 168 x 159 mm
Notes Brown
External source of data Ernst Erb
Source of data Collector's Guide to Antique Radios 4. Edition
Circuit diagram reference Rider's Perpetual, Volume 12 = ca. 1941 and before
Mentioned in Guide to Old Radios
Literature/Schematics (1) RCA Victor Service Notes "Red Book" Series


All listed radios etc. from RCA (RCA Victor Co. Inc.); New York (NY)
