1-YC-11 Ch= RS-196 + TCT-3A

1-YC-11 Ch= RS-196 + TCT-3A; RCA RCA Victor Co. (ID = 163591) R-Player
Use red slider bar for more.
1-YC-11 Ch= RS-196 + TCT-3A; RCA RCA Victor Co. (ID = 163591) R-Player
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  United States of America (USA)
Manufacturer / Brand:  RCA (RCA Victor Co. Inc.); New York (NY)
alternative name

RCA Manufacturing || Victor Talking Machine
Year: 1961 ? Category: Sound/Video Recorder and/or Player
Valves / Tubes 4: 6EU7 6EU7 6DR7 EM84
Main principle Audio-Amplification
Details Tape Recorder
Power type and voltage Alternating Current supply (AC) / 120 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: 1-YC-11 Ch= RS-196 + TCT-3A - RCA RCA Victor Co. Inc.; New
Notes RS-196 amplifier chassis
TCT-3A tape transport
Circuit diagram reference Beitman Radio Diagrams Vol. 22, 1962
