• Year
  • 1941
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 53407
    • alternative name: RCA Manufacturing || Victor Talking Machine

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 6
  • Main principle
  • Superheterodyne (common); ZF/IF 455 kHz
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • AC/DC-set / 105-125 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 5 inch = 12.7 cm
  • Power out
  • 1.4 W (unknown quality)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: 36X Ch= RC-1011 - RCA RCA Victor Co. Inc.; New
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 14.7 x 8.11 x 7.5 inch / 373 x 206 x 191 mm
  • Notes
  • Pilot lamp mazda no. 51, 6-8 volts, 0.2 amp. Frequency range: 540-1620 kc. Loudspeaker impedance: 4 ohms at 400 cycles.
  • External source of data
  • Ernst Erb
  • Circuit diagram reference
  • Rider's Perpetual, Volume 14 = 1944 = before 1943
  • Literature/Schematics (1)
  • RCA Victor Instruments Service Notes 1941-1942
