3-X-532 ; RCA RCA Victor Co. (ID = 502254) Radio
RCA RCA Victor Co.: 3-X-532 [Radio] ID = 502254 933x684
Select picture or schematic to display from thumbnails on the right and click for download.
For model 3-X-532, RCA (RCA Victor Co. Inc.); New York (NY)

Country:  United States of America (USA)
Manufacturer / Brand:  RCA (RCA Victor Co. Inc.); New York (NY)
alternative name

RCA Manufacturing || Victor Talking Machine
Year: 1954 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 12BE6 12BA6 12AV6 50C5 35W4
Main principle Superheterodyne (common); ZF/IF 456 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage AC/DC-set / 110 - 120 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
Power out
from Radiomuseum.org Model: 3-X-532 - RCA RCA Victor Co. Inc.; New
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel without bush buttons, Mantel/Midget/Compact up to 14
Dimensions (WHD) 240 x 140 x 150 mm / 9.4 x 5.5 x 5.9 inch
Net weight (2.2 lb = 1 kg) 1.6 kg / 3 lb 8.4 oz (3.524 lb)
Source of data Collector's Guide to Antique Radios (7th Edition)
Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Date 1-54, Set 226, Folder 7)

Model page created by Karol Gillon. See "Data change" for further contributors.
