612V2 Ch=RK-121 RS-123
RCA (RCA Victor Co. Inc.); New York (NY)
- Country
- United States of America (USA)
- Manufacturer / Brand
- RCA (RCA Victor Co. Inc.); New York (NY)
- Year
- 1946/1947
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 184586
-
- alternative name: RCA Manufacturing || Victor Talking Machine
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 12
- Main principle
- Superhet with RF-stage
- Wave bands
- Broadcast, Short Wave plus FM or UHF.
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 117 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 12 inch = 30.5 cm
- Power out
- 10 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 612V2 Ch=RK-121 RS-123 - RCA RCA Victor Co. Inc.; New
- Shape
- Console with Push Buttons.
- Notes
- Three built-in antennas - one for each band; connection for outside aerial. Available in butt walnut, mahogany or blonde veneers.
- Mentioned in
- Radio Retailing (Radio & Television R.) (January 1947 page 52.)
- Literature/Schematics (4)
- Photofact Folder, Howard W. SAMS (Set 17, Date 4/47, Folder 477-27)
- Author
- Model page created by Ernst Erb. See "Data change" for further contributors.
