- Country
- United States of America (USA)
- Manufacturer / Brand
- RCA (RCA Victor Co. Inc.); New York (NY)
- Year
- 1946/1947
- Category
- Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)
- Radiomuseum.org ID
- 120520
-
- alternative name: RCA Manufacturing || Victor Talking Machine
From a RCA Prospect
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 47
- Valves / Tubes
- Main principle
- Superheterodyne (common)
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 115 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 648PTK - RCA RCA Victor Co. Inc.; New
- Shape
- Console, Lowboy (legs < 50 %).
- Dimensions (WHD)
- 36.25 x 47.5 x 22.75 inch / 921 x 1207 x 578 mm
- Notes
- Projection TV with 15 by 20" screen, MW/SW and FM radio with 8 push-buttons, US standard VHF tuner, uses PTU-1 unit.
- Mentioned in
- -- Original prospect or advert
- Literature/Schematics (1)
- Radio Retailing (Radio & Television R.) (November 1946 page 148.)
- Literature/Schematics (2)
- E. Costa, Introduzione alla Televisione, Editore U.Hoepli, 1951
- Author
- Model page created by a member from A. See "Data change" for further contributors.
- Other Models
-
Here you find 5126 models, 3229 with images and 4161 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from RCA (RCA Victor Co. Inc.); New York (NY)
