6JM

6JM ; RCA RCA Victor Co. (ID = 1108999) R-Player

6JM ; RCA RCA Victor Co. (ID = 1109000) R-Player
6JM ; RCA RCA Victor Co. (ID = 749364) R-Player 6JM ; RCA RCA Victor Co. (ID = 749365) R-Player
6JM ; RCA RCA Victor Co. (ID = 749366) R-Player 6JM ; RCA RCA Victor Co. (ID = 749367) R-Player
Use red slider bar for more.
6JM ; RCA RCA Victor Co. (ID = 749364) R-Player
RCA RCA Victor Co.: 6JM [R-Player] ID = 749364 802x600
Select picture or schematic to display from thumbnails on the right and click for download.
For model 6JM, RCA (RCA Victor Co. Inc.); New York (NY)

Country:  United States of America (USA)
Manufacturer / Brand:  RCA (RCA Victor Co. Inc.); New York (NY)
alternative name

RCA Manufacturing || Victor Talking Machine
Year: 1946–1948 Category: Sound/Video Recorder and/or Player
Wave bands - without
Details Record Player (not changer)
Power type and voltage Alternating Current supply (AC) / 105-125 Volt
Loudspeaker - For headphones or amp.
Power out 20 W (unknown quality)
from Radiomuseum.org Model: 6JM - RCA RCA Victor Co. Inc.; New
Material Bakelite case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 315 x 105 x 225 mm / 12.4 x 4.1 x 8.9 inch
Notes Tone arm is let in flush and locked by pushing it down; unlocked by pushing it to the right.
Der Tonarm versenkt und arretiert sich indem man daraufdrückt. Durch das Schieben nach rechts löst sich die Arretierung wieder.
This is the 50Hz model.
Net weight (2.2 lb = 1 kg) 2.4 kg / 5 lb 4.6 oz (5.286 lb)
Source of data - - Data from my own collection
Literature/Schematics (1) RCA Victor Service Notes "Red Book" Series (RCA Victor Service Data 1943-1946, Page 3)

Model page created by Guido Höh. See "Data change" for further contributors.
