• Country
• United States of America (USA)

• Manufacturer / Brand
• RCA (RCA Victor Co. Inc.); New York (NY)

• Year
• 1950/1951

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 231333

• • alternative name: RCA Manufacturing || Victor Talking Machine

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 24

• Valves / Tubes
• 6AG5 6AG5 6J6 6AU6 6AU6 6AL5 6AV6 6K6GT 6BA6 6AG5 6BA6 6AG5 6AL5 12AU7 6SN7GT 6SN7GT 6SN7GT 6K6GT 6SN7GT 6BG6G 6W4GT 1B3GT or 8016 5U4G 16GP4

• Main principle
• Superhet with RF-stage

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Alternating Current supply (AC) / 60 cycles, 115 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 inch = 30.5 cm

• Power out
• 3.5 W (max.)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 6T72 Ch= KCS40B - RCA RCA Victor Co. Inc.; New

• Shape
• Console with any shape - in general

• Dimensions (WHD)
• 28 x 37.125 x 23.375 inch / 711 x 943 x 594 mm

• Notes

• The RCA 6T72 is a 16" b/w TV with US standard VHF tuner channels 2 thru 13. Equipped with picture tube 16GP4.  Cabinet color is Walnut, Mahogany or Oak.

• Net weight (2.2 lb = 1 kg)
• 116 lb (116 lb 0 oz) / 52.664 kg

• Literature/Schematics (1)
• RCA Victor Service Notes "Red Book" Series (RCA Victor Service Data Volume VI 1950 Pages 401-412)

• Author
• Model page created by John Kusching. See "Data change" for further contributors.
