7X ; RCA RCA Victor Co. (ID = 2371321) Radio
RCA RCA Victor Co.: 7X [Radio] ID = 2371321 1400x1045
Select picture or schematic to display from thumbnails on the right and click for download.
For model 7X, RCA (RCA Victor Co. Inc.); New York (NY)

Country:  United States of America (USA)
Manufacturer / Brand:  RCA (RCA Victor Co. Inc.); New York (NY)
alternative name

RCA Manufacturing || Victor Talking Machine
Year: 1936 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: 6L7 6J7 6K7 6H6 6J7 25A6 25Z6
Main principle Super-Heterodyne (Super in general); ZF/IF 460 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Short Wave(s) and Police.
Details
Power type and voltage AC/DC-set / 105-125 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12.5 cm = 4.9 inch
Power out 0.6 W (unknown quality)
from Radiomuseum.org Model: 7X - RCA RCA Victor Co. Inc.; New
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 470 x 325 x 230 mm / 18.5 x 12.8 x 9.1 inch
Notes same chassis as in 7X1.
Net weight (2.2 lb = 1 kg) 27 lb (27 lb 0 oz) / 12.258 kg
Price in first year of sale 50.00 USD
Collectors' prices
External source of data Ernst Erb
Source of data The Radio Collector's Directory and Price Guide 1921 - 1965
Circuit diagram reference Rider's Perpetual, Volume 8 = 1937 and before
Mentioned in Collector's Guide to Antique Radios (6th edition)
Literature/Schematics (1) RCA Victor Service Notes "Red Book" Series
Literature/Schematics (2) Cathedral & Tombstone Radios (page 213.)


All listed radios etc. from RCA (RCA Victor Co. Inc.); New York (NY)
