For model 97KG, RCA (RCA Victor Co. Inc.); New York (NY)

Country:  United States of America (USA)
Manufacturer / Brand:  RCA (RCA Victor Co. Inc.); New York (NY)
alternative name

RCA Manufacturing || Victor Talking Machine
Year: 1938/1939 perfect model Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: 6K8 6K7 6H6 6F5 6U5 6F6 5W4
Main principle Superheterodyne (common); ZF/IF 455 kHz
Wave bands Broadcast plus 2 Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 105-125 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 12 inch = 30.5 cm
Power out 2.5 W (unknown quality)
from Radiomuseum.org Model: 97KG - RCA RCA Victor Co. Inc.; New
Material Wooden case
Shape Console with Push Buttons.
Dimensions (WHD) 32 x 35 x 12.7 inch / 813 x 889 x 323 mm
Notes

The grand cabinet console model 97KG is an Electric Tuning radio with "Straight-Line Dial", "Victrola Push-Button Switch" and "Plug-In" for Victrola Attachment. Pilot lamp is a Mazda 44, 6.3 v.
The RCA ad in Life, September 5, 1938 offered on page 37 the models 97KG ($ 85), 95T5 ($ 24.95), 96T2 ($ 39.95) and 96T ($ 29.95) for season 1938/39, called 1939 models.

External source of data Ernst Erb
Source of data The Radio Collector's Directory and Price Guide 1921 - 1965
Circuit diagram reference Rider's Perpetual, Volume 9 = 1938 and before
Mentioned in Collector's Guide to Antique Radios 4. Edition
Literature/Schematics (1) Pre-War Consoles (RCA Victor Service Notes for 1938)
