9T79 "Northampton" Ch= KCS49A

RCA (RCA Victor Co. Inc.); New York (NY)

  • Year
  • 1950/1951
perfect model
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 231340
    • alternative name: RCA Manufacturing || Victor Talking Machine

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 22
  • Main principle
  • Superhet with RF-stage
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Power type and voltage
  • Alternating Current supply (AC) / 60 cycles, 115 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 inch = 30.5 cm
  • Power out
  • 3.5 W (max.)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: 9T79 "Northampton" Ch= KCS49A - RCA RCA Victor Co. Inc.; New
  • Shape
  • Console with any shape - in general
  • Dimensions (WHD)
  • 30.25 x 40 x 26.25 inch / 768 x 1016 x 667 mm
  • Notes
  • The RCA 9T79 is a 19" b/w TV with US standard VHF tuner channels 2 thru 13. Equipped with picture tube 19AP4A.  Cabinet color is Mahogany, Walnut or Limed Oak.

    The TV alignment data and waveform photographs can be found in RCA model 6T53 data (Pages 372 to 385 in RCA Victor Service Data Volume VI 1950).

    Model Chassis Matrix
    Model TV Chassis Chassis Differences
    9T57 KCS49 Vertical Sweep Oscillator Tube 6J5
    9T57 KCS49T Vertical Sweep Oscillator Tube 6SN7GT
    9T77 KCS49A Vertical Sweep Oscillator Tube 6J5, addition of pilot light, channel indicator light and switch
    9T77 KCS49AT Vertical Sweep Oscillator Tube 6SN7GT, addition of pilot light, channel indicator light and switch
    9T79 KCS49A Vertical Sweep Oscillator Tube 6J5, addition of pilot light, channel indicator light and switch
    9T79 KCS49AT Vertical Sweep Oscillator Tube 6SN7GT, addition of pilot light, channel indicator light and switch



  • Net weight (2.2 lb = 1 kg)
  • 136 lb (136 lb 0 oz) / 61.744 kg
  • Source of data
  • - - Manufacturers Literature
  • Author
  • Model page created by John Kusching. See "Data change" for further contributors.
